About Us


2D into 3D, and Beyond

We have 20 years experience with Solidworks 3D CAD.  Much of our work has been in Commercial HVAC Mechanical Systems and all related equipment...even before BIM.


Beyond HVAC we have designed other equipment using structural weldments in various industries.


You DREAM IT...WE DESIGN IT!

Custom dry product filling and bagging system

Customers

Manufacturers Representatives

Manufacturers

Contractors

Engineers

Custom Systems


When your customer INSIST on 3D

Give it to them!

Many manufacturers use Solidworks in their manufacturing.  These models are very detailed, proprietary designs that they will not release to the public domain.  Therefore they must take on the additional expense of duplicating their product models as a simple solid for the public.  Many of these manufacturers have not budgeted this expense.



Manufacturers Challenges

Commercial HVAC systems are largely composed of "Engineer Specified Products", custom designed.  This makes the provision of 3D models all the more difficult.  We have solutions for these products, configuring them from their parametric components.


The Process

Send us your 2D design/product drawing and we will provide you with a quote.  If the quote is acceptable we go to work.  On completion of the 3D model we will send you images to review.  Payment can be processed by credit card and the 3D files will be sent to you.


The best universal file type is ".SAT" which will import directly into Revit, AutoCAD MEP, and many other platforms.  Solidworks has a long list of export file types so we can match your needs.



Other Services

If your design needs are more detailed please call to discuss.  We frequently work under Non-Disclosure Agreements for your security.
